Type AR mechanical seal, is used in pumps domestic and industrial, Rotary turbines and centrifugal in millimeter sizes. It works with hydraulic fluid and aqueous solutions, depending on the combination of materials.
MATERIALS
Rotary Face: Carbon Graphite, Silicon Carbide.
Seat: Ceramic, Silicon Carbide.
Bellows: NBR, FKM, EPDM.
Metallic Parts: Stainless Steel 304
OPERATION LIMITS
Shaft Speed: Max 3,600 R.P.M. (Depends on the diameter of the shaft).
Pressure: 75 PSI (5.3Kg/cm2) (It depends on the combination of the material of the faces).
Temperature limits: -57 °C a 204 °C (Depends on the material of the elastomer).
